NEW QUESTION # 149
When an engineer was debugging a wireless network at a customer site, the radio frequency tuning function configured on the device did not take effect. The engineer checked the current radio frequency tuning status on the wireless controller, and the following was displayed. After analyzing the displayed information, which of the following may be the cause of the failure of radio frequency calibration?
- A. The channel and power automatic selection functions are disabled on the device.
- B. AP did not detect neighbor information
- C. No VAP template is configured on the device
- D. Device tuning is not completed
Answer: A
NEW QUESTION # 150
In the Portal authentication process based on the HTTP/HTTPS protocol, after the user enters the username and password on the Portal authentication page, the client initiates a Portal authentication request to the Porta1 server, and then the Porta1 server notifies the client to initiate a Portal authentication request to the AAA server.
- A. False
- B. True
Answer: A
NEW QUESTION # 151
When installing and deploying an AP, the AP can use an Ethernet cable for PoE power supply.
Which of the following descriptions of the PoE protocol are correct? (Multiple choice)
- A. The maximum output power of the power supply equipment supporting the POE+ protocol is 60 watts
- B. The power supply standard of PoE++ technology is IEEE 802.3bt
- C. The maximum output power of the power supply equipment supporting the POE protocol is 15.4 watts
- D. The maximum output power of a power supply device that supports the PoE+ protocol is 30 watts
Answer: B,C,D
NEW QUESTION # 152
In the WAC+FITAP networking scenario, CAPWAP tunnels support both IPv4 and IPv6 dual stacks. However, when deploying a WLAN network, it is not recommended to have both IPv4 APs and IPv6 APs in one area, otherwise it will affect services such as spectrum navigation, smart roaming, and load balancing.
- A. False
- B. True
Answer: B
NEW QUESTION # 153
The alarm information on the Huawei wireless controller web interface is divided into emergency, important, minor, and prompt according to the severity from high to low. In daily maintenance, emergency, important,/minor, and prompt level alarms need to be handled in a timely manner.
- A. False
- B. True
Answer: A
NEW QUESTION # 154
To prevent non-critical services from occupying too much network resources, QoS policies can be configured in application protocols, namely smart application control SAC. Which of the following descriptions of SAC functions is wrong?
- A. In roaming scenarios, the SAC policy of the user after roaming is based on the policy issued by the device accessed after roaming.
- B. For the identified application protocol packets, their priority can be modified or directly discarded
- C. SAC mainly detects and identifies the 4th to 7th layer content and some dynamic protocols (such as HTTP, RTP) in the message, and implements refined QoS policy control based on the classification results
- D. When a CAPWAP tunnel is established between WAC and AP to centrally forward user messages, the SAC service will be deployed on the AP.
Answer: A
NEW QUESTION # 155
In the Portal authentication scenario, if the Portal server only supports the HTTPS protocol, the access device needs to execute the "portal web-authen-server" command to enable the Portal docking function of the HTTPS protocol. By default, the HTTPS terminal number used by the access device is ()
Answer:
Explanation:
8443
NEW QUESTION # 156
Drag and Drop Question
In Huawei's intelligent roaming solution, both APs and terminals support the 802.11k protocol.
Please sort the following WAC roaming target selection process.
Answer:
Explanation:
NEW QUESTION # 157
In the hotel wireless coverage scenario, which of the following descriptions of the guest room scenario network plan are correct? (Multiple choice)
- A. APs outside the room that cover the corridor should be installed away from the door of the guest room.
- B. If the guest rooms are separated by solid walls, APs can be deployed at equal intervals in the corridor to save costs.
- C. When installing RU or panel AP in a room, it is usually installed under the table using 86 box or wall mounting.
- D. If the guest rooms are separated by solid walls, it is recommended to place one RU or panel AP in each room to ensure user experience.
Answer: A,B,C,D
NEW QUESTION # 158
What configuration methods does the wireless controller support? (Multiple choice)
- A. Console port configuration
- B. LLDP configuration
- C. Telnet configuration
- D. Configuring through eSight
Answer: A,C,D
NEW QUESTION # 159
In the 802.11 frame, the terminal needs to send () control message to obtain access to the wireless medium.
Answer:
Explanation:
RTS
NEW QUESTION # 160
In WLAN network planning in crowded scenarios such as lecture halls or banquet halls, due to the large number of concurrent users, engineers will give priority to APs with fewer MIMOs but more radio frequencies when selecting AP models.
- A. False
- B. True
Answer: A
NEW QUESTION # 161
The acceptance index of WLAN capacity design is to ensure that the bandwidth of key services can meet the needs of concurrent users in the target area.
- A. False
- B. True
Answer: B
NEW QUESTION # 162
In the medical infusion hall scenario, the indoor floor height is 35 meters, the user distribution is 2 square meters per person, and the business types include web browsing, games, videos, and instant messaging.
Which of the following network deployment suggestions for this scenario is wrong?
- A. It is recommended to use indoor directional AP and wall mount it.
- B. Install the AP away from interference sources
- C. It is recommended to deploy APs at equal intervals of 15 to 18 meters
- D. It is recommended to install the AP at least 3 meters away from the load-bearing column.
Answer: A
NEW QUESTION # 163
Which of the following descriptions of Huawei terminal plug-in test solutions is wrong?
- A. The terminal needs to install a special "dial test APP" on the mobile phone to collect data
- B. Xserver acts as a data site, providing intranet test platform, vMos test plug-in, etc.
- C. CampusInsight is used as the background analysis tool, which is responsible for receiving and analyzing the data reported by the APP.
- D. Terminal dial test is a test method for network link quality, which detects Wi-Fi user experience, network quality, link status and other information
Answer: A
NEW QUESTION # 164
......
